Cattle Feed Pellet Machine

High-efficiency flat die pelletizer designed to convert raw mash into nutrient-dense pellets for livestock and poultry.

Key Features

High Compression Ratio

Advanced ring die technology designed to produce high-density, uniform pellets for optimal nutrition.

Automatic Lubrication

Continuous oiling system ensures smooth operation and extends the lifespan of the bearings and gearbox.

Adjustable Pellet Sizing

Easily interchangeable dies allow for pellet diameters ranging from 2mm to 10mm to suit various livestock.

Robust Drive System

Equipped with high-torque gearboxes and heavy-duty motors for reliable, 24/7 industrial performance.

Applications

Livestock & Dairy Farming
Commercial Feed Mills
Poultry Feed Production
Aquafeed Processing
Organic Fertilizer Pelleting

Technical Specifications

Specification Details
Production Capacity 500 – 2,000 kg/hour
Main Motor Power 22 – 90 kW
Pellet Diameter 2 – 10 mm
Ring Die Speed 250 – 300 RPM
Steam Pressure 0.2 – 0.4 MPa
Machine Weight 1,500 – 3,500 kg
Machine Dimensions 2200 x 1800 x 2400 mm

Optional Features

Stainless steel steam conditioner
Magnetic raw material separator
Integrated pellet cooling unit
VFD for automated feeder control

Why Choose Sabi Energy?

Sabi Energy provides reliable biomass preparation equipment designed for high efficiency, durability, and consistent performance. Contact us today for customization, pricing, and technical consultation.
